• Lamps, Smoked Amber roof marker
• Headlamps, halogen projector-beam
• Grille, base, molded in color, Black
• Wheels, 19.5" x 6.75", steel, Black painted, 8-holes, hub piloted (STD)
• Front fender extension, painted body color
• Lamps, cargo area, cab mounted with switch on center switch bank
• Lamps, rear, stop/turn/backup (1-piece assembly) with license plate light
• Grille guard screen, insect protection (mounted behind grille)
• Antenna, fixed mast
• Spare tire delete (STD)
• Wheel, spare delete
• Door handles, Black
• Provision for cab roof-mounted lamp/beacon provides an overhead console mounted switch and electrical wiring tucked beneath the headliner for a body upfitter to connect a body-mounted warning or emergency lamp
• Tires, rear 225/70R19.5G traction Goodyear Range Max Max Axle Load: 15,000 lbs.
• Auxiliary harness, 3' for headlamps and turn signals
• Mirrors, outside heated power-adjustable vertical trailering, upper glass, manual-folding and extending, black. Includes integrated turn signal indicators consisting of 51 square inch flat mirror surface positioned over a 24.5 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated and not power adjustable) and addition of Auxiliary cargo lamp for backing up (helps to see trailer when backing up with a trailer) and amber auxiliary clearance lamp
• Glass, deep-tinted
• Spare tire delete (STD)
• Wheels, 19.5" x 6.75", steel, Black painted, 8-holes, hub piloted (STD)
• Taillamp wiring harness provisions includes wiring for standard left and right taillamps, separate 8 feet of extra cable wiring for left and right body-mounted taillights
• Fog lamps, front, halogen
• Paint, solid
• Assist Steps, aluminum
• Air Dryer, heated
• Red Hot
• Tires, front 225/70R19.5G highway Goodyear Range Max Max Axle Load: 7,940 lbs.
• Air Compressor Accessory Drive
• Bumper, front chrome

• Door locks, power
• Air conditioning, single-zone
• Seat Belt, Black
• Assist handle, front passenger and driver on A-pillars
• Floor covering, Graphite-colored rubberized-vinyl
• Steering wheel, urethane
• Upfitter switch kit provides up to 4-30 amp circuits to facilitate installation of aftermarket electrical accessories located on the instrument panel
• Steering column, manual Tilt-Wheel
• Mirror, inside rearview manual day/night
• Visors, driver and front passenger, vinyl
• Driver Information Center, 3.5" diagonal monochromatic display provides warning messages and basic vehicle information
• Seat trim, Vinyl
• Seat, rear 60/40 folding bench (folds up), 3-passenger (includes child seat top tether anchor)
• Windows, power with driver express up and down and express down on all other windows
• Speedometer, miles/kilometers
• Interior trim, Jet Black/Dark Ash (Required and only available with (H2Q/H2R) Dark Ash seats with Jet Black interior accents.)
• Cruise control, steering wheel-mounted
• Remote Keyless Entry
• Defogger, rear-window electric
• Seats, front 40/20/40 split-bench, 3-passenger driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar. (STD)
• Dark Ash seats with Jet Black interior accents, Vinyl seat trim
• Back-up alarm calibration This calibration will allow installation of an aftermarket back-up alarm by disabling rear perimeter lighting
• Key system, 2 spare keys
• Power outlet, 120-volt AC

• Axle, Open rear axle, non-locking rear
• Capped Fuel Fill
• Steering, power (Bosch S2 8014 Plus)
• Fuel tank, rear only, 40 gallon mounted between frame side rails and behind rear axle
• Emissions, USA 50 State certified
• Trailer brake controller, integrated
• Incomplete vehicle
• Fuel, diesel B20
• Axle lubricant, rear, synthetic oil EmGard FE -75W-90
• Rear axle, 4.30 ratio Max road speed: 79 MPH
• Trailering provisions, trailering wire harness only, trailer combined (Stop/Tail/Turn) connection socket and harness mounted at rear of frame.
• Front axle, 7,500 lbs, Dana Spicer 60-256, single-reduction, front driving
• Axle lubricant, front, synthetic oil EmGard FE-75W-90
• Exhaust brake
• Four wheel drive
• Emissions, 50 state certification
• Front suspension, 7,500 lbs. (3,402 kg) multi-leaf, includes shock absorbers
• Brakes, hydraulic, heavy duty Bosch/Meritor/Wabco system with 4-channel (ABS) (Includes (J69) driveline park brake.)
• Differential, heavy-duty locking rear
• Rear suspension, 13,500 lbs. (6,123 kg) multi-leaf, vari-rate
• Rear axle, 4.30 ratio Max road speed: 79 MPH
• Power Take-Off (PTO), not installed
• 5500 HD Series
• GVWR, 18,000 lbs. (8165 kg)
• Prop Shaft Guard, steel
• Wheelbase, 199" (505.5 cm), 84" CA
• Skid Plate, steel, frame-mounted, protects the transfer case from the ground
• Exhaust system, straight, terminates ahead of rear wheels
• Alternator, 220 amps
• Batteries, heavy-duty dual 1300 cold-cranking amps includes battery box mounted to left side under cab
• Additional fuel, 5 gallons
• Rear axle, 15,500 lb. (7,031 kg)
• Axle to End of Frame, 63"
• High idle switch
• Battery, top post threaded, battery jump start stud (located on battery box)
• 26,000 lbs. GCWR (11,793 kg)

• Snow Plow Prep Package includes (UNL) auxiliary harness for headlamps and turn signals, (KW5) 220-amp alternator, forward lamp wiring harness and (TRW) provision for cab roof mounted lamp/beacon
• WT Preferred Equipment Group includes standard equipment

• Daytime Running Lamps, with automatic exterior lamp control

• Rear Vision Camera, display integrated into Radio (Shipped loose in cab for upfitter installation.)
• OnStar, delete
• Airbag deactivation switch, frontal passenger-side (Included and only available with (AY0) airbags.)
• Airbags, Single-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front and rear outboard seating positions; (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• Horn, Trumpet Style, single-note
• Backup alarm (Includes (SFW) SEO Calibration for backup alarm.

• StabiliTrak, Electronic Stability Control System with Traction Control includes Electronic Trailer Sway Control and Hill Start Assist
• Brake, parking, driveline park brake system
• Traction control

Snow Plow Prep Package

• DriveType
• DriveType: Four Wheel Drive
• Fuel Economy
• City: 0
• Hwy: 0
• Combined: 0
• Fuel System
• Fuel System: Direct Injection
• Fuel Tank Capacity
• Fuel Tank Capacity: 40 gal
• Fuel Type
• Fuel Type: Diesel Fuel
• Horse Power
• Horse Power: 350
• Rear Wheel
• Rear Wheel: Dual
• Trailering Capacity
• Trailering Capacity: 0
